Mercury 40 FourStroke User Manual

TILLER HANDLE
90-857046R1 NOVEMBER 2001 Page 7B-3
TILLER HANDLE
REF
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in lb-ft Nm.
1 1 COVER KIT
2 1 PULLEY
3 1 CASE
4 1 SCREW (10-16 x 1/2 IN. Self Tapping) 20 2.3
5 1 THROTTLE CABLE (30-1/2 IN.)
6 1 THROTTLE CABLE (41-1/2 IN.)
7 1 SLEEVE
8 2 SCREW (M8 x 25) 135 15.3
9 1 COVER
10 1 BUSHING
11 1 ARM–Steering Handle
12 1 RETAINER
13 1 SCREW (M5 x 16) 35 3.9
14 1 SCREW (M6 x 25)
15 1 LOCK–Throttle
16 1 SPRING
17 1 KNOB–Throttle
18 1 TILLER TUBE
19 1 DECAL
20 1 HANDLE–Throttle
21 1 GRIP
22 1 SWITCH (STOP)
23 1 SHIFT ROD
24 1 TAB WASHER
25 2 SCREW (M10 x 90) 35 47.5
26 2 CLIP
27 1 SWITCH (STOP)
28 1 RETAINER
29 1 BRACKET–Tiller
30 1 WAVE WASHER
31 1 BUSHING
32 1 WASHER
33 1 CONDUIT
34 1 CABLE TIE
35 1 DECAL-Shift (F-N-R)
36 1 LANYARD SWITCH
37 1 SCREW (M8 x 35) 100 11.3
38 1 SHIFT HANDLE
39 1 BUSHING
