MANUAL STARTER
90-857046R1 NOVEMBER 2001 Page 8-5
Manual Starter Removal
1. Remove the adjustment screw from the rewind housing.
2. Remove the retaining clip from the start interlock.
3. Remove the interlock cable.
a
b
a-Adjustment Screw
b-Retaining Clip
4. Remove screws and manual starter.
a
b
a-Screw (4) M6x25
b-
Manual Starter
