CYLINDER HEAD
90-857046R1 NOVEMBER 2001 Page 4A-13
Valve Cover
NOTE: Valves should be adjusted when engine is cold.
WARNING
Engine could possibly start when turning flywheel during adjustment. To prevent
this type of accidental engine starting and possible serious injury, always remove
spark plug leads from spark plugs.
Removal
1. Disconnect spark plug leads and remove spark plugs.
2. Remove flywheel cover/manual starter components (if equipped).
3. Remove lower cowl (if desired) for easier access to lower screws.
NOTE: Refer to section 8 for removal of manual starter.
a
b
a-Screw (4) M6 x 25
b-Flywheel Cover
To Next Page
