BIGFOOT GEAR HOUSING
90-857046R1 NOVEMBER 2001 Page 6B-29
Forward Gear Bearing Race
IMPORTANT: Retain shim(s) for reassembly. If shims are damaged, replace with new
shims of equal thickness.
1. Remove race and shim(s) using Slide Hammer (91-34569A1).
27653
a
b
91-34569A1
c
a- Race
b- Shim(s)
c- Slide Hammer (91-34569A1)
