WIRING DIAGRAMS
90-857046R1 NOVEMBER 2001 Page 2D-19
Remote Key
1. Connect the remote key harness and engine harness, secure harness in holder.
–
+
1 2345 6 78
12
345678
PPL
PPL
BLK
YEL/RED
BLK/YEL
RED
YEL/BLK
PPL
TAN
e
BLK = Black
BLU = Blue
BRN = Brown
GRY = Gray
GRN = Green
ORN = Orange
PNK = Pink
PUR = Purple
RED = Red
TAN = Tan
WHT = White
YEL = Yellow
LT = Light
DRK = Dark
BLK_YEL
PPL
YEL_BLK
TAN
BLK
YEL_RED
RED
a
b
c
f
d
a-Keyswitch Assembly Transom Mount
b-Keyswitch
c-Horn
d-Remote Key Harness Connector
e-Engine Harness Connector
f-Harness Connector Holder
