Mercury 40 FourStroke - Reassembly - O-Ring and Seal Placement

MANUAL TILT ASSIST
90-857046R1 NOVEMBER 2001 Page 5C-27
Reassembly - O-Ring and Seal Placement
1
2
3
5
4
14
6
7
9
11
12
10
13
8
NOTE: Lubricate all O-rings using Power Trim and Steering Fluid. If not available, use auto-
motive (ATF) automatic transmission fluid.
NOTE: It is recommended that all o-rings be replaced when servicing tilt system.
