CYLINDER HEAD
90-857046R1 NOVEMBER 2001 Page 4A-15
Installation
1. Install valve cover seal into groove.
2. If removed, reinstall baffle plate. Tighten screws securely.
a
c
b
a-Baffle Plate
b-Screw (4) M4 x 10
c-Cover Seal
