CYLINDER BLOCK/CRANKCASE
Page 4B-12 90-857046R1 NOVEMBER 2001
Removing Powerhead Components
1. Place powerhead on bench.
Ignition Components
1. Refer to Section 2A for removal of the following ignition components.
a. Flywheel
b. Stator
c. Timing Belt
d. Ignition Coils
e. ECM
f. Crank Position Sensor
g. Temperature Sensor
Charging and Starting System Components
1. Refer to Section 2B for removal of the following ignition components.
a. Starter Motor
b. Start Solenoid
c. Voltage Regulator
Fuel Components
1. Refer to Section 3A and 3B for removal of the following components.
a. Fuel Pump
b. Carburetor
Harness and Battery Cable Removal
1. Remove battery and harness cable assembly.
Cylinder Head Removal
1. Refer to Section 4A for cylinder head removal.
