IGNITION
Page 2A-32 90-857046R1 NOVEMBER 2001
Engine Coolant Temperature (ECT) Sensor
Removal/Installation
1. Disconnect sensor from wiring harness.
2. Remove sensor from exhaust cover.
3. Reverse steps for installation. Tighten to specified torque.
CAUTION
Over-tightening the engine coolant temperature sensor can lead to failing the plas-
tic threads. Be sure to tighten to the specified torque.
b
58225
a
c
a-Harness Connector
b-Temperature Sensor
c-Exhaust Cover
Temperature Sensor Mounting Torque
15 lb. in. (1.5 N·m)
To Next Page
