CYLINDER BLOCK/CRANKCASE
Page 4B-1190-857046R1 NOVEMBER 2001
9. Disconnect the crankcase vent hose.
10. Disconnect inlet hose from fuel pump.
a
b
59250
a-Crankcase Vent Hose
b-Fuel Pump Inlet hose
11. Remove powerhead mounting bolts.
12. Lift powerhead from driveshaft housing.
b
a
a-Powerhead Mounting Bolts (4 Each Side) M8 x 45
b-Hoist
