CYLINDER BLOCK/CRANKCASE
Page 4B-10 90-857046R1 NOVEMBER 2001
7. Push retainer up and slide over to disengage the vertical shift shaft.
REMOTE CONTROL MODEL (NON - BIGFOOT)
a
1
2
a-Retainer
8. Remove the shift guide bracket screws.
TILLER HANDLE MODEL
58479
a
b
a-Shift Guide Bracket
b-Screw (2) M6 x 25
