CHARGING & STARTING SYSTEM
90-857046R1 NOVEMBER 2001 Page 2B-5
Wiring Diagram (15 Ampere) (S/N OG960500 and Up)
BLK = Black
GRY = Gray
RED = Red
YEL = Yellow
e
c
b
a
YELYEL
YEL
YEL
GRY
RED
RED
BLK
BLK
RED
RED
f
d
a-Stator
b-Voltage Regulator/Rectifier
c-Connector
d-To Engine Ground
e-To Battery Positive (Red) Terminal
f-To Battery Negative (Black) Terminal
