Mercury 40 FourStroke User Manual

WIRING DIAGRAMS
90-857046R1 NOVEMBER 2001 Page 2D-9
IMPORTANT: On installations where gauge options will not be used, tape back and
isolate any unused wiring harness leads.
BATT
GND
SENDER
STARBOARD INSTALLATION
5265
4
j
i
a
g
m
f
e
o
k-Lanyard/Diode
l-“Y” Harness
m-Power Trim Harness Connector
n-Connect Wires Together with Screw and Hex
Nut (4 Places);Apply Liquid Neoprene to Con-
nections and Slide Rubber Sleeve over Each
Connection.
o-Lead to Visual Warning Kit
