CARBURETOR
Page 3B-26 90-857046R1 NOVEMBER 2001
3. Install plunger and spring.
4. Install gasket bowl and float.
a
b
c
d
e
f
a-Screws (4)
b-Float Bowl
c-Plunger
d-Spring
e-Gasket
f-Retaining Screw
