CARBURETOR
90-857046R1 NOVEMBER 2001 Page 3B-31
2. Connect auto enrichener wires, breather hose, fuel supply hose, and bowl vent hoses.
b
c
a
d
e
a-Auto Enrichener Wires (Yellow)
b-Breather Hose
c-Fuel Supply Hose
d-Bowl Vent Hose (if equipped)
e-Through Hole in Adaptor Plate
NOTE: Carburetor synchronization is required after rebuilding carburetors. Refer to section
2C, Timing/Synchronizing/Adjusting.
