CYLINDER BLOCK/CRANKCASE
Page 4B-590-857046R1 NOVEMBER 2001
CRANKSHAFT
REF
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in lb-ft Nm.
1 1 CRANKSHAFT
2 1 OIL SEAL
3 1 OIL SEAL
4 4 CONNECTING ROD
5 6 BOLT 150 12.5 17
6 BEARING (BROWN)
6
6 BEARING (BLACK)
6 BEARING (BLUE)
7 3 PISTON
8 3 PISTON RING (TOP)
9 3 PISTON RING (SECOND)
10 3 PISTON OIL RING
11 3 PISTON PIN
12 6 RETAINER
