CYLINDER BLOCK/CRANKCASE
Page 4B-790-857046R1 NOVEMBER 2001
CYLINDER BLOCK AND CRANKCASE
TORQUE
.
NO.
QTY. DESCRIPTION lb-in lb-ft Nm.
1 1 CYLINDER BLOCK
2 2 DOWEL PIN
3 3 PLUG 79 9
4 1 PIPE PLUG (1/2-14) 24 33
5 1 PIPE PLUG (3/4-14) 24 33
8 BEARING (BROWN)
6
8 BEARING (BLACK)
8 BEARING (BLUE)
7 1 NIPPLE 29.5 40
8 8 SCREW (M8 X 82) 22 30
9 8 SCREW (M6 X 35) 106 12
10 1 GASKET
11 1 OIL FILTER 70 8
12 1 GASKET
13 1 EXHAUST COVER
14 1 PIPE PLUG Drive Tight
15 1 THERMOSTAT
16 1 GASKET
17 1 COVER
18 10 SCREW (M6 X 35) 106 12
19 1 ELBOW Drive Tight
20 3 STA STRAP
21 1 TUBING (10 IN.)
22 1 ENGINE COOLANT TEMPERATURE (ECT) SENSOR 15 1.5
23 1 O RING
24 1 LIFTING EYE
25 1 SCREW (M8 X 35) 29 39.5
26 1 HOSE (19 IN.)
