CLAMP/SWIVEL BRACKETS & DRIVE SHAFT HOUSING
90-857046R1 NOVEMBER 2001 Page 5A-3
Transom Bracket
REF
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in. lb-ft Nm
1 1 TRANSOM BRACKET (PORT)
2 1 GREASE FITTING
3 1 GROOVE PIN
4 1 TRANSOM BRACKET (STARBOARD)
5 1 TILT LOCK LEVER
6 1 SPRING
7 1 NYLINER
8 1 SPRING
9 1 KNOB
10 1 GROOVE PIN
11 2 WASHER
12 1 ANCHOR BRACKET
13 1 ANODE ASSEMBLY
14 2 SCREW (M6 x 25) 60 7
15 2 WASHER
16
5 SCREW (30 MM)
16
1 SCREW (35 MM)
17 4 LOCKWASHER
18 2 NUT
19 1 TILT PIN ASSEMBLY NON POWER TRIM
20 1 SPRING
21 1 TILT TUBE
22 2 NUT
Tighten nut to 32 lb.
ft. and then back off
1/4 turn
23 1 SEAL KIT
24 1 O RING NON-HANDLE
25 1 SPACER
26 2 CLIP
27 1 C-WASHER POWER TRIM
28 1 SCREW Drive Tight
29 4 SCREW Drive Tight
30 4 WASHER Drive Tight
31 4 NUT
32 1 LINK
33 1 TILT LEVER
34 1 BUSHING NON POWER TRIM
35 1 WASHER
36 1 WAVE WASHER
37 1 TILT KNOB
38 1 SCREW (.375-16 x .62) 18 25
39 2 SCREW (M10 x 40)
40
2 WASHER
41
2 NUT
42
1 DECAL-Tilt Lock
