CLAMP/SWIVEL BRACKETS & DRIVE SHAFT HOUSING
90-857046R1 NOVEMBER 2001 Page 5A-5
Swivel Bracket
TORQUE
.
NO.
QTY. DESCRIPTION lb-in. lb-ft Nm
1 1 LINK ROD
2 1
SCREW (1-1/2 IN.) 20 27.0
3 1 WASHER NON HANDLE
4 2 WASHER
5 2 NUT (.375-24) 120 13.5
6 1 PUCK
7 1 BUSHING
8 1 SWIVEL BRACKET
9 2 BEARING
10 2 GREASE FITTING (Quantity 3 required on Handle Versions)
11 1 DECAL-Co-Pilot
12 1 DECAL-Serial Overlaminate
13 1 BUSHING (LOWER)
14 1 SEAL
1 SCREW (M8 x 10) (HANDLE)
15
1 SCREW (M8 x 25) NON HANDLE
16 1 SEAL
