CLAMP/SWIVEL BRACKETS & DRIVE SHAFT HOUSING
90-857046R1 NOVEMBER 2001 Page 5A-11
Steering Arm
REF
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in. lb-ft Nm
1 2 NUT 50 68
2 1 STRAP
3 2 MOUNT
4 2 WASHER (BIGFOOT)
5 8 SCREW (M6 x 20) 130 15
6 1 BUMPER
7 1 BUMPER (BIGFOOT)
8 1 RETAINING RING
9 1 STEERING ARM
10 1 BRACKET
11 1
TAB WASHER NON HANDLE
12 2 SCREW (M10 x 30) 32.5 44
13 2 SCREW (M12 x 154) 24 32.5
14
1 SPACER (SHORT)
14
1 SPACER (LONG)
15
1 SWIVEL TUBE (SHORT)
15
1 SWIVEL TUBE (LONG)
16 1 GROUND STRAP
17 1 GROUND STRAP
18 2 SCREW (M10 x 105) 32.5 44
19 1 BRACKET
20 3 SCREW(SELF–TAPPING) Drive Tight
21 2 NUT 32.5 44
22 1 NUT (.375-24)
23 1 LEVER–Co-Pilot
24 1 WASHER
25 1 ROD (THREADED) HANDLE
26 1 BRACKET PLATE
27 1 DISC
28 1 PLATE
29 1 DISC
30 2 SCREW (Hex Shoulder) 70 8
