CLAMP/SWIVEL BRACKETS & DRIVE SHAFT HOUSING
90-857046R1 NOVEMBER 2001 Page 5A-13
Bottom Cowl
REF
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in. lb-ft Nm
1
1 BOTTOM COWL (SHORT-PORT)
1
1 BOTTOM COWL (LONG-PORT)
2
1 BOTTOM COWL (SHORT-STBD.)
2
1 BOTTOM COWL (LONG-STBD.)
3 6 SCREW (M6 X 30) 60 7
4 1 WASHER
5 1 SEAL
6 1 WASHER
7 1 GASKET
8 1 SCREW (M6 x 60) 60 7
9 1 FITTING-TELLTALE
10 1 BOOT
11 2 STA-STRAP
12 1 LEVER-COWL LATCH
13 2 BUSHING
14 2 WAVE WASHER
15 1 LATCH HOOK
16 1 SCREW (M6 x 16) 60 7
17
1 GROMMET (NON POWER TRIM)
17
1 GROMMET (SPLIT - POWER TRIM)
18 1 PLUG- Trim Switch (NON POWER TRIM)
19 1 SWITCH (POWER TRIM)
20
1 RETAINER
21
1 GROMMET
