POWER TRIM
90-857046R1 NOVEMBER 2001 Page 5B-5
Power Trim
REF
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in. lb-ft Nm
– 1 POWER TRIM PUMP
1 1 SHOCK ROD KIT
2 1 MEMORY PISTON ASSEMBLY
3 1 O RING REBUILD KIT
4 2 O RING
5 1 CYLINDER ASSEMBLY
6
1 TRIM LIMIT VALVE KIT (NON-BIGFOOT)
6
1 TRIM LIMIT VALVE KIT (BIGFOOT)
7 1 PUMP ASSEMBLY
8 1 MOTOR KIT
9 1 RESERVOIR PLUG
10 1 MANUAL RELEASE ASSEMBLY
11 1 MANIFOLD KIT
12 1 SCREW KIT (MOTOR)
13 1 DRIVE SHAFT
14 1 FILTER KIT
15 1 P.O. CHECK ASSEMBLY KIT
16 1 CABLE
– 1 O RING KIT (COMPLETE TRIM)
17 2 TRILOBE PIN
18 1 ANCHOR PIN
19 1 PIN
A - Torque cylinder cap to 45 lb-ft (61 Nm)
B - Torque screws to 80 lb-in. (9.0 Nm)
C - Torque screws to 70 lb-in. (7.9 Nm)
D - Torque plugs to 120 lb-in. (13.5 Nm)
E - Torque screws to 100 lb-in. (11 Nm)
F - Torque shock piston to 90 lb-ft (122 Nm)
