MANUAL TILT ASSIST
90-857046R1 NOVEMBER 2001 Page 5C-3
Manual Tilt Components
REF
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in. lb-ft Nm
1 1 SHOCK ROD ASSEMBLY
2 1 MEMORY PISTON ASSEMBLY
3 1 O RING REBUILD KIT-Cylinder
4 2 O RING
5 1 CYLINDER ASSEMBLY
6 1 SCREW AND SEAL KIT
7 1 ACCUMULATOR ASSEMBLY 35 47
8 1 VALVE BODY ASSEMBLY
9 1 CAM KIT
10 1 VELOCITY VALVE KIT
11 1 CHECK SYSTEM REPAIR KIT
– 1 O RING KIT
12 1 CABLE
13 2 PIN
14 2 TRILOBE PIN
a
– Torque cylinder cap to 45 lb-ft (61 Nm)
b
– Torque Accumulator to 35 lb-ft (47 Nm)
c
– Torque Velocity Valve to 75 lb-in. (8.5 Nm)
d
– Torque Transfer Valve Plug to 75 lb-in. (8.5 Nm)
e
– Torque Screw to 100 lb-in. (11 Nm)
f
– Torque Shock Piston to 90 lb-ft (122 Nm)
