NON-BIGFOOT GEAR HOUSING
Page 6A-790-857046R1 NOVEMBER 2001
Gear Housing (Driveshaft)(2:1 Gear Ratio)
TORQUE
.
NO.
QTY. DESCRIPTION lb-in. lb-ft Nm
– 1 GEAR HOUSING (SHORT)
– 1 GEAR HOUSING (LONG)
1 1 GEAR HOUSING (BASIC)
2 1 SEAL/PLATE KIT
3 1 PLATE (Part Of Ref #2)
4 1 SCREW (.375-16 x .25) 60 7
5 1 WASHER-Sealing
6 1 DRAIN SCREW 60 7
7 1 WASHER-Sealing
8 1 NUT 50 68
9 1 PINION GEAR (13 TEETH)
10 1 BEARING ASSEMBLY-Roller
11 1 CUP (Part Of Ref #10)
12 4 SCREW (M6 x 16) 60 7
13 1 WATER PUMP ASSEMBLY
1 SEAL-Water Tube (SHORT - 1-3/4)
14
1 SEAL-Water Tube (LONG - 2-1/4)
15 1 WASHER
16 1 KEY
17 1 WASHER
18 1 GASKET
19 1 GASKET (LOWER)
20 1 BASE PLATE
21 1 IMPELLER
22 1 WATER PUMP BASE ASSEMBLY
23 1 SEAL-Oil
24 1 SEAL-Oil
25 1 O RING
1 DRIVESHAFT (SHORT)
26
1 DRIVESHAFT (LONG)
27 1 BALL BEARING
28 1 CABLE TIE
29 1 BOOT-Shift Shaft
30 1 RETAINER-Shift Shaft
31 1 O RING
32 1 O RING
33 1 WASHER
1 SHIFT SHAFT (SHORT)
34
1 SHIFT SHAFT (LONG)
35 1 WASHER
36 1 ROLL PIN
37 1 CAM-Shift
38 1 PIN
