BIGFOOT GEAR HOUSING
90-857046R1 NOVEMBER 2001 Page 6B-35
8. Install O-ring. Lubricate O-ring and propshaft seal lips with 2-4-C Marine Lubricant with
Teflon.
9. Lubricate outside diameter of reverse gear bearing and bearing carrier bore with a light
coating of 2-4-C Marine Lubricant with Teflon.
10. Press bearing into carrier until tool bottoms.
19163
a
b
c
95 2-4-C Marine Lubricant with Teflon
95
91-13945
a- O-ring
b- Bearing, Numbered Side Toward Tool
c- Bearing Installation Tool (91-13945)
11. Install thrust washer. Coat thrust washer with Premium Gear Lubricant.
19167
a
87
Premium Gear Lubricant
87
a- Thrust Washer
To Next Page
