THROTTLE/SHIFT LINKAGE
90-857046R1 NOVEMBER 2001 Page 7A-3
LINKAGE (NON BIGFOOT)
TORQUE
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 1 SCREW (M8 x 70) 100 11.3
2 1 SCREW (M6 x 55)
3 1
NUT ELECTRIC
4 1 CAP
5 1 RETAINER
6 1 THROTTLE LEVER
7 1 BUSHING
8 1 RETAINER
9 1 SHIFT LEVER
10 1 BRACKET NON HANDLE
11 1 LATCH
12 2 SCREW (M6 x 16) 75 8.5
13 2 SLEEVE
14 1 SHIFT ROD
15 1 THROTTLE CAM
16 1 SPACER
17 1 WASHER
18 1 SCREW (M5 x 16) 75 8.5
19 1 HORIZONTAL SHIFT SHAFT
20 1 RETAINER
21 1 WASHER
22 1 COTTER PIN
23 1 SPRING
24 2 SPRING
25 1 PLATE
26 2 SCREW (M5 x 16)
27 1 SWITCH
28 2 SCREW (M3 x 20) ELECTRIC HANDLE MODELS
29 1 PLATE–Switch
