THROTTLE/SHIFT LINKAGE
90-857046R1 NOVEMBER 2001 Page 7A-5
LINKAGE (BIGFOOT)
REF
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 1 SCREW (M8 x 70) 100 11.3
2 1 SCREW (M6 x 55)
3 1 NUT
4 1 CAP
5 1 RETAINER
6 1 THROTTLE LEVER
7 1 BUSHING
8 1 RETAINER
9 1 SHIFT LEVER
10 1 BRACKET
11 1 LATCH
12 2 SCREW (M6 x 16) 75 8.5
13 2 SLEEVE
14 1 SHIFT ROD
15 1 GUIDE-Shift Rod
16 1 SHIFT LINK
17 2 NYLINER
18 2 WASHER
19 1 NUT
20 1 COTTER PIN
21 1 SHIFT SHAFT LEVER
22 1 BUSHING
23 1 THROTTLE CAM
24 1 SPACER
25 1 WASHER
26 1 SCREW (M5 x 16) 75 8.5
27 1 SWIVEL LINKAGE (MANUAL BIGFOOT)
28 1 SHIFT ROD (MANUAL BIGFOOT)
29 1 SHIFT ROD (MANUAL BIGFOOT)
30 1 SHIFT DETENT (MANUAL BIGFOOT)
31 1 SPRING (MANUAL BIGFOOT)
32 1 SWITCH ELECTRIC
33 1
PLATE–Switch HANDLE MODELS
34 2 SCREW (M3 x 20)
