Mercury 40 FourStroke User Manual

MANUAL STARTER
90-857046R1 NOVEMBER 2001 Page 8-3
MANUAL STARTER
REF
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
– 1 RECOIL STARTER ASSEMBLY
1 1 RECOIL HOUSING
2 1 SEAL
3 1 ROLLER
4 1 BUSHING
5 1 WASHER
6 1 SCREW (M6 x 30) 70 8.0
7 1 WASHER-Finger Spring
8 1 SPRING
9 1 STARTER SHEAVE
10 2 DOG-CAM
11 2 SPRING
12 2 RETAINING RING
13 1 SPRING
14 1 CAM
15 1 SCREW (1/4-20) 135 15.3
16 1 STARTER CORD
17 1 CAM
18 1 SPRING
19 1 INTERLOCK LEVER
20 1 RETAINER
21 1 SPRING
22 1 BUSHING
23 5 SCREW (10-16 x 1) Drive Tight
24 1 HANDLE
25 1 RETAINER
26 4 SCREW (M6 x 25) 60 7.0
27 1 INTERLOCK CABLE
28 1 SCREW (10-16 x .625) Drive Tight
29 1 WASHER
30 1 COTTER PIN
31 1 SCREW (M5 x 16) 33.6 3.8
32 1 DECAL-EPA Information
