MANUAL STARTER
90-857046R1 NOVEMBER 2001 Page 8-11
2. Back sheave off until knot recess in sheave aligns with rope bushing.
a
b
a-Rope Bushing
b-Knot Recess
3. Thread starter rope thru knot recess in starter sheave, rope guide, and starter housing.
Place knot into recess.
a
b
a-Starter Rope
b-Knot
