MANUAL STARTER
90-857046R1 NOVEMBER 2001 Page 8-13
8. Install cam retainer. Drive screws tight.
NOTE: Cam should be held with some pre-load until retainer is seated.
a
c
b
a-Cam Retainer
b-Cam
c-Screw (3) 10-16x.625
NOTE: Hold interlock lever back and check the operation of the rewind and rewind tension
before installation.
