30/40 (4-Stroke) Tiller Handle Electric 2001 Models and
Newer (S/N 0T178500 and Up)
1. ECM
2. Crank Position Sensor
3. Temperature Sensor
4. Oil Switch
5. DDT Connection
6. Auto Enrichener
7. Stator
8. Tachometer Signal (Secondary)
9. Voltage Regulator
10. Starter
11. Start Solenoid
12. To Trim Motor
13. Trim Down Relay
14. Trim Up Relay
15. To 12 Volt Battery
16. Panel Mounted Trim Switch
17. 12 Volt Switched Auxiliary Power Source
18. Key Switch
19. Warning Horn
20. Push Button Stop Switch
21. Lanyard Stop Switch
22. Tachometer Signal
23. Cowl Mounted Trim Switch
24. Neutral Start Switch
25. Tiller Handle Harness Connection
26. Engine Harness Connection
27. To Warning Lamps
28. 20 Amp. Fuse
29. 20 Amp. Fuse
30. Ignition Coil #1
31. Ignition Coil #2
32. Ignition Coil #3
33. Diode
