IGNITION
90-857046R1 NOVEMBER 2001 Page 2A-7
FLYWHEEL
REF
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 1 FLYWHEEL COVER ELECTRIC
2 4
SCREW (M6 x 25) 45 5.0
3 1 DECAL-EPA Information
4 1 FLYWHEEL (ELECTRIC)
5 1 FLYWHEEL (MANUAL)
6 1 DECAL-Warning Spinning flywheel
7 1 DECAL-Timing Marks
8 1 DECAL-Warning-Neutral
9 1 NUT 116 157
10 1 WASHER
11
3 SCREW (M5 x 25) (MANUAL) 85 9.5
11
3 SCREW (M5 x 30) (ELECTRIC) 85 9.5
12 1 STATOR (OG 960499 and Below)
13 1 STATOR (OG 960500 and Up)
14 1 LOAD RING
