IGNITION
90-857046R1 NOVEMBER 2001 Page 2A-9
ELECTRICAL COMPONENTS
REF
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 1 SOLENOID ASSEMBLY
2 2
BUSHING
3 2 GROMMET
4 2 NUT (8-32) (ELECTRIC) 25 3.0
5 3 NUT (1/4-20) 60 7.0
6 1 BATTERY CABLE (POSITIVE)
7 1 INSULATOR BOOT
8 1 CABLE
9 1 BATTERY CABLE (NEGATIVE)
10 1 STARTER MOTOR (See breakdown on Starter Motor)
11
3 SCREW (M8 x 45) (ELECTRIC) 21.5 29.5
11
1 SCREW (M8 x 25) (MANUAL) 21.5 29.5
12
2 SCREW (M6 x 30) (ELECTRIC) 75 8.5
12
1 SCREW (M6 x 16) (MANUAL) 75 8.5
13 1 J CLIP (ELECTRIC)
14 1 PRESSURE SWITCH 75 8.5
15 1 SENSOR-Crank Position
16 2 SCREW (M5 x 16) 45 5.0
17 3 SCREW (M6 x 25) 75 8.5
18 3 WASHER
19 1 PLATE
20 3 BUSHING
21 3 GROMMET
22 1 ECM
23 3 BUSHING
24 3 SCREW (M6 x 40) 45 5.0
25 3 SPARK PLUG (NGK DPR6EA-9) 12.5 17
1 DECAL-Coil Identification (1#)
26
1 DECAL-Coil Identification (2#)
26
1 DECAL-Coil Identification (3#)
27 3 IGNITION COIL
28 3 SCREW (M6 x 20) 75 8.5
29
1 ENGINE WIRING HARNESS (MANUAL)
29
1 ENGINE WIRING HARNESS (ELECTRIC)
30 1 FUSE (SFE 20 AMP) (ELECTRIC)
31 1 COVER (ELECTRIC)
32 1 CLAMP (ELECTRIC)
33 2 SCREW (M6 x 16) (ELECTRIC)
34 1 HARNESS-EXTENSION (ELECTRIC HANDLE)
35 AR STA-STRAP
36 1 J CLIP (MANUAL)
37 1 VOLTAGE REGULATOR (S/N OG960499 and Below)
38 1 VOLTAGE REGULATOR (S/N OG960500 and Up)
39 1 J-CLIP
40
2 SCREW (M6 x 40) ELECTRIC 105 12.0
40
1 SCREW (MANUAL)
41 1 SCREW (M6 x 10)
42 1 PLUG
43 1 SCREW (M6 x 16)
