6 System Commissioning and Functions NICE3000
new
User Manual
- 120 -
6
■ Asynchronous motor auto-tuning
a. Asynchronous motor with-load auto-tuning ((motor connected with car)
START
Func.
Code
Parameter Name Default Commissioning
Enter inspection state
Turn the Automatic/Inspection switch to the Inspection position.
X9 indicator is OFF, indicating that the elevator enters inspection state.
Select command source F0-01 Command source selection 1 0
0: Operation panel control
1: Distance control
Set motor type F1-25 Motor type 1 0
0: Asynchronous motor
1: Synchronous motor
Set motor parameters Motor Nameplate
Be sure that motor parameters are set correctly. Otherwise, faults will
occur.
F1-01 Rated motor power Model dependent
Unit: kW
F1-02 Rated motor voltage Model dependent
Unit: V
F1-03 Rated motor current Model dependent
Unit: A
F1-04 Rated motor frequency Model dependent
Unit: Hz
F1-05 Rated motor speed Model dependent
Unit: RPM
Set encoder parameters F1-00 Encoder type 0
0: SIN/COS encoder
1: UVW encoder
2: ABZ incremental encoder
3: ECN413/1313 absolute encoder
Set F1-00 according to the actual encoder type.
F1-12
Encoder pulses per
revolution
2048
Set this parameter according to the encoder nameplate.
