NICE3000
new
User Manual 8 Description of Function Codes
- 229 -
starts counting again.
If this parameter is set to 0, this function is disabled.
8.13 Operation Panel Parameter Display
8.13.1 Parameter Display in Running/Stop State
Function Code Parameter Name Setting Range Default Unit Property
FA-01
Display in running state 1–65535 65535 -
☆
It is used to set the running parameters displayed on the operation panel when the elevator is in the
running state.
FA-01 includes 16 binary bits, each deîš¿ning a parameter. A total of 16 parameters can be can be displayed
during running.
The 16 binary bits correspond to the running parameters listed in the following table.
Bit Parameter Name Default Bit Parameter Name Default
Bit0 Running speed 1 Bit8 Output terminal 1
Bit1 Set speed 1 Bit9 Current oor 1
Bit2 Bus voltage 1 Bit10 Current position 1
Bit3 Output voltage 1 Bit11 Car load 1
Bit4 Output current 1 Bit12 CTB input state 1
Bit5 Output frequency 1 Bit13 CTB output state 1
Bit6 Input terminal low bits 1 Bit14 System state 1
Bit7 Input terminal high bits 1 Bit15 Pre-toque current 1
The method of setting FA-01 is as follows:
If a bit is set to 1, the parameter indicated by this bit is displayed; if this bit is set to 0, the parameter is not
displayed.
Convert the sum of binary values of all 16 bits to decimal, and then set the decimal on the operation panel.
