Page #68 background imageLoading...
Page #68 background image
NICE3000
new
User Manual
4 Peripheral Devices and Options
- 67 -
4
4.1.3 Peripheral Device Selection
â—†
Cable Selection
Table 4-2 Recommended cable sizes
Controller Model Main Circuit Cable (mm
2
) Control Circuit Cable (mm
2
) Grounding Cable (mm
2
)
Single-phase 220 V, range:220–240 V, 50/60 Hz
NICE-L-C-2002
1 0.75 1
NICE-L-C-2003
2.5 0.75 2.5
220-NICE-L-C-4007
4 0.75 4
220-NICE-L-C-4011
6 0.75 6
220-NICE-L-C-4015
6 0.75 6
220-NICE-L-C-4018
6 0.75 6
220-NICE-L-C-4022
10 0.75 10
220-NICE-L-C-4030
16 0.75 16
Three-phase 220 V, range: 220–240 V, 50/60 Hz
NICE-L-C-2002
1.5 0.75 1.5
NICE-L-C-2003
2.5 0.75 2.5
220-NICE-L-C-4007
4 0.75 4
220-NICE-L-C-4011
6 0.75 6
220-NICE-L-C-4015
6 0.75 6
220-NICE-L-C-4018
10 0.75 10
220-NICE-L-C-4022
10 0.75 10
220-NICE-L-C-4030
16 0.75 16
Three-phase 380 V, range: 380–440 V, 50/60 Hz
NICE-L-C-4002
0.75 0.75 0.75
NICE-L-C-4003
1.5 0.75 1.5
NICE-L-C-4005
2.5 0.75 2.5
NICE-L-C-4007
4 0.75 4
NICE-L-C-4011
6 0.75 6
NICE-L-C-4015
6 0.75 6
NICE-L-C-4018
10 0.75 10
NICE-L-C-4022
10 0.75 10
NICE-L-C-4030
16 0.75 16
NICE-L-C-4037
25 1.0 16
NICE-L-C-4045
35 1.0 16
NICE-L-C-4055
50 1.0 25
NICE-L-C-4075
70 1.0 35
NICE-L-C-4090
95 1.0 50
NICE-L-C-4110
120 1.0 60
NICE-L-C-4132
120 1.0 60
NICE-L-C-4160
150 1.0 75
