Monarch nice3000 User Manual

NICE3000
new
User Manual 8 Description of Function Codes
- 219 -
8
Bit Function Description Default
Bit6
Continuous buzzer tweeting
in attendant state
When the hall call oor and the car call oor are different, the
buzzer tweets continuously.
0
Bit7
Car call button blinking to
prompt
When the hall call input is active, the car call button for the
corresponding oor blinks to give a prompt.
0
8.8.7 Emergency Evacuation Function
Function Code Parameter Name Setting Range Default Unit Property
F8-09
Emergency evacuation operation speed
at power failure
0.000 to F3-11 0.050 m/s
★
F3-22
Acceleration rate at emergency
evacuation
0.100–1.300 0.100 m/s
2
★
F8-10
Emergency evacuation operation mode
at power failure
0–2 0 -
★
F6-45
Emergency evacuation function
selection
0–65535 0 -
★
F6-49
Emergency evacuation parking oor 0 to F6-00 0 -
★
F8-09 is used to set the speed for emergency evacuation operation at power failure.
F3-22 is used to set the acceleration rate at emergency evacuation.
F8-10 is used to set the emergency evacuation operation mode at power failure.
●
0: Motor not running
●
1: UPS
●
2: 48 V battery power supply
F6-45 is used to select the attendant-related elevator functions. Each bit of the function code denes a
function, as described in the following table.
If a bit is set to 1, the function indicated by this bit is enabled; if this bit is set to 0, the function is disabled.
For details on how to view and set this function code, see the descriptions in section 8.21.1.
When F6-45 Bit2 = 1, the elevator stops at the emergency evacuation parking oor set in F6-49.
When F6-45 Bit2 = 0, the elevator stops at the nearest landing oor.
The functions dened by the binary bits of F6-45 are described in the following table.
Bit Function Description Default
Bit0
Direction determine
mode
0
Automatically
calculating direction
0
Load direction
determining (based on
load cell data or half-
load signal)
1
Direction of
nearest landing
oor
0
Bit1 0 1 0
Bit2
Stopping at
evacuation parking
oor
During evacuation running, the elevator arrives at the evacuation parking
oor set in F6-49 (it must be a non-zero value and is a service oor).
Otherwise, the elevator stops at the nearest oor.
0
Bit3 Reserved - 0
Bit4
Compensation at
startup
The non-load-cell startup is still valid in the process of evacuation running. 0
