NICE3000
new
User Manual 8 Description of Function Codes
- 195 -
8
8.2 Motor Parameters
8.2.1 Motor Type and Parameters
Function Code Parameter Name Setting Range Default Unit Property
F1-25
Motor type
0: Asynchronous motor
1: Synchronous motor
1 -
F1-01
Rated motor power 0.7–75.0 Model dependent kW
F1-02
Rated motor voltage 0–600 Model dependent V
F1-03
Rated motor current 0.00–655.00 Model dependent A
F1-04
Rated motor frequency 0.00–99.00 Model dependent Hz
F1-05
Rated motor speed 0–3000 Model dependent RPM
Set these parameters according to the motor type and motor nameplate.
8.2.2 Encoder Parameters
Function Code Parameter Name Setting Range Default Unit Property
F1-00
Encoder type
0: SIN/COS encoder
1: UVW encoder
2: ABZ incremental encoder
3: ECN413/1313 absolute
encoder
0 -
F1-10
Encoder verication selection 0–65535 0 -
F1-12
Encoder pulses per revolution 0–10000 2048 PPR
When F1-25 is set to 1 (Synchronous motor), set this parameter correctly before auto-tuning;
otherwise, the motor cannot run properly.
When F1-25 is set to 0 (Asynchronous motor), this parameter is automatically changed to 2. You
need not modify it manually.
F1-10 is used to set encoder signal verication. This parameter is set by the manufacturer, and you need
not modify it generally.
F1-12 is used to set the pulses per revolution of the encoder (according to the encoder nameplate).
8.2.3 Motor Auto-tuning Mode
Function Code Parameter Name Setting Range Default Unit Property
F1-11
Auto-tuning mode
0: No operation
1: With-load auto-tuning
2: No-load auto-tuning
3: Shaft auto-tuning
0 -
