NICE3000
new
User Manual 8 Description of Function Codes
- 249 -
8
8.17 Communication Parameters and HCB/HCB-B Terminal Function
Selection
8.17.1 Communication Parameters
Function Code Parameter Name Setting Range Default Unit Property
Fd-00
Baud rate
0: 9600
1: 38400
0 bps
★
Fd-02
Local address
0–127
0: Broadcast address
1 -
★
Fd-03
Communication response delay 0–20 10 ms
★
Fd-04
Communication timeout
0.0–60.0
0: Invalid
0.0 s
★
These RS232 serial port communication parameters are used for monitor software communication in the
host computer.
Fd-00 species the baud rate for serial communication. Fd-02 species the address of the controller. The
setting of these two parameters must be consistent with the setting of the serial port parameters on the
host computer.
Fd-03 species the delay for the controller to send data by means of the serial port.
Fd-04 species the communication timeout time of the serial port. Transmission of each frame must be
completed within the time set in Fd-04; otherwise, a communication fault occurs.
8.17.2 HCB Terminal Function Selection
Function Code Parameter Name Setting Range Default Unit Property
Fd-07
HCB:JP1 input
0: Reserved
1: Elevator lock signal
2: Fire emergency signal
3: Present oor forbidden
4: VIP oor signal
5: Security oor signal
6 Door close button signal
7: Second re emergency oor signal
1 -
★
Fd-08
HCB:JP2 input 2 -
★
These parameters are used to set the functions of pins 2 and 3 of JP1 and JP2 on the HCB.
The setting is effective to the HCBs at all oors.
