6 System Commissioning and Functions NICE3000
new
User Manual
- 154 -
Bit
Function
Description
Binary Setting Remarks
Bit13
Mode of shorting
stator braking
mode switched
over to controller
drive
1 Speed setting
If the speed is still lower than
the value set in F6-48 after the
elevator is in shorting stator
braking mode for 10s, the
controller starts to drive the
elevator.
0 Time setting
If the time of the shorting stator
braking mode exceeds 50s,
the controller starts to drive the
elevator.
Bit14
Emergency
evacuation exit
mode
1 Exit at door close limit -
0 Exit at door open limit -
Bit15
Shorting stator
braking function
1 Enable this function.
When this function is enabled,
the setting of related function
codes becomes effective.
6.2.3 Parallel/Group Control
The NICE3000
new
provides the function of elevator parallel or group control:
●
Parallel control of 2 elevators implemented by directly using the CAN communication port
●
Group control of multiple elevators with together use of the group control board
◆
Parallel Control
1. Default parallel control scheme (CAN communication port CN3)
The following table describes the parameter setting of parallel control implemented at the CAN
communication port CN3.
Function Code Parameter Name Setting Range Setting in Parallel Control Remarks
F6-07
Number of elevators in
parallel/group mode
1–8 2
F6-08 Elevator No. 1–8
Master elevator: 1
Slave elevator: 2
F5-30 Y5 function selection - 14 (Controller healthy)
Assume that Y5 is
used as the transfer
relay.
When the CAN communication port (CN3) is used to implement parallel control, you need to set the
CTB addresses, as described in the following table.
CTB Jumper Setting Description
CTB of elevator 1#
Short J2 at the OFF position or do not connect it. Set the
CTB as the master (address: 1).
CTB of elevator 2#
Short J2 at the ON position or do not connect it. Set the CTB
as the slave (address: 2).
To Next Page
