Monarch nice3000 User Manual

NICE3000
new
User Manual
6 System Commissioning and Functions
- 153 -
6
Function Code Parameter Name Value Remarks
F5-20 (X20) X20 function selection
27 (Emergency
evacuation signal)
Assume that X20 is used as
the NO input of emergency
evacuation signal.
NOTE
● Select the ARD with the nominal output power equal to or larger than the rated motor power.
● For the 380 V elevator ARD, only two phases are used for emergency evacuation output, and
you need to ensure that wiring to the controller is correct; the output is single-phase 380 V, and
you need to ensure that the transformer meets the requirements on the input side.
3. Other parameters related to emergency evacuation
Function Code Parameter Name Setting Range
F3-22 Acceleration rate at emergency evacuation 0.100–1.300 m/s
2
F6-48 Emergency evacuation switching speed 0.010–0.630 m/s
F6-49 Evacuation parking oor 0 to F6-00
F8-09 Emergency evacuation operation speed at power failure 0.05 m/s
The detailed description of F6-45 is as follows.
Bit
Function
Description
Binary Setting Remarks
Bit0
Direction
determine mode
0
Automatically
calculating
the direction
0
Load direction
determining
(based on
load cell data
or half-load
signal)
1
Direction
of nearest
landing
oor
If the torque direction is
automatically calculated, the
no-load-cell function must be
enabled, that is, F8-01 is set to
2.
Bit1 0 1 0
Bit2 Stop position
1 Stop at the base oor -
0 Stop at nearest landing oor -
Bit4
Startup
compensation
1
Startup torque compensation valid in emergency
evacuation running
When it is set that the torque
direction is automatically
calculated, automatic startup
torque compensation is
enabled.
Bit8
Emergency
evacuation
running time
protection
1
If the elevator does not arrive at the required oor
after 50s emergency evacuation running time,
E33 is reported.
This function is invalid when
the function of switching over
shorting stator braking mode to
controller drive is used.
Bit10
Emergency buzzer
output
1
The buzzer output is active during UPS
emergency evacuation running.
-
Bit12
Shorting stator
braking mode
switched over to
controller drive
1
Enable the function of switching over the shorting
stator braking mode to controller drive.
-
