NICE3000
new
User Manual 8 Description of Function Codes
- 207 -
direction at power failure.
72: Fire emergency oor switchover signal
The NICE3000
new
supports two re emergency oors. By default, the elevator stops at re emergency
oor 1 in re emergency state. If this signal is active, the elevator stops at re emergency oor 2 in re
emergency state.
76: Door 1 open input 77: Door 2 open input
8.6.2 Function Selection of Higher-Voltage DI Terminals
Function Code Parameter Name Setting Range Default Unit Property
F5-37
X25 function selection
0: Invalid
4: Safety circuit signal
5: Door lock circuit signal
0 -
★
F5-38
X26 function selection 0 -
★
F5-39
X27 function selection 0 -
★
These parameters are used to set signals input to heavy-current detection input terminals X25 to X27.
8.6.3 Function Selection of DO Terminals
Function Code Parameter Name Setting Range Default Unit Property
F5-26
Y1 function selection
0–31
1 -
★
F5-27
Y2 function selection 2 -
★
F5-28
Y3 function selection 3 -
★
F5-29
Y4 function selection 4 -
★
F5-30
Y5 function selection 0 -
★
F5-31
Y6 function selection 0 -
★
These parameters are used to set signals output by relay output terminals Y1 to Y6.
00: Invalid
The terminal has no function.
01: RUN contactor control 02: Brake contactor control 03: Shorting door lock circuit contactor
control
The terminal with one of these signals controls whether the contactor is opened or closed.
04: Fire emergency oor arrival signal feedback
In the îš¿re emergency state, the system sends the feedback signal for monitoring after the elevator stops at
the re emergency oor.
05: Door machine 1 open 06: Door machine 1 close 07: Door machine 2 open 08: Door
machine 2 close
The terminal with one of these signals is used to control open and close of door 1 or 2.
09: Brake and RUN contactors healthy
When the brake and RUN contactors operate properly (non-Err36/Err37 state), the system sends the
