NICE3000
new
User Manual 8 Description of Function Codes
- 241 -
8
8.13.7 Hall State and System State Display
Function Code Parameter Name Setting Range Default Unit Property
FA-35
Hall sate 0–65535 0
-
FA-36
System state 1 0–65535 0
-
FA-37
System state 2 0–65535 0
-
They are used to display the car input and output states.
Figure 8-26 FA-35 Hall state
RUN LOCAL/REMOT FED/REV TUNE/TC
0
1
24
5
3
6
7
8
9
10
14
11
12
13
15
Present signal No.
State of present
signal
Each segment
indicates a signal
Segment ON: active
Segment OFF: inactive
Display
Meaning
Active
Inactive
...
No. Signal
No.
Signal
0
1
2
3
4
5
7
Elevator lock signal
Fire emergency signal
Current floor forbidden
VIP signal
Security signal
Door close button input
Reserved
8
9
10
12
13
14
15
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
11
Reserved
6
