8 Description of Function Codes NICE3000
new
User Manual
- 240 -
8
Figure 8-24 FA-33 Car input state
RUN
LOCAL/REMOT FED/REV TUNE/TC
0
1
2
4
5
3
6
7
8
9
10
14
11
12
13
15
Present signal No.
State of present
signal
Each segment
indicates a signal
Segment ON: active
Segment OFF: inactive
Display
Meaning Active Inactive
...
No. Signal No. Signal
0
1
2
3
4
5
7
Door 1 light curtain
Door 2 light curtain
Door 1 open limit
Door 2 open limit
Door 1 close limit
Door 2 close limit
Full-load input
8
9
10
12
13
14
15
Overload input
Light-load input
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
11 Reserved
6
Figure 8-25 FA-34 Car output state
RUN
LOCAL/
REMOT FED/REV TUNE/
TC
0
1
24
5
3
6
7
8
9
10
14
11
12
13
15
Present signal No.
State of present
signal
Each segment
indicates a signal
Segment ON: active
Segment OFF: inactive
Display
Meaning
Active
Inactive
...
No.
Signal No.
Signal
0
1
2
3
4
5
7
Door 1 open
Door 1 close
Forced door close 1
Door 2 open
Door 2 close
Forced door close 2
Up arrival gong
8
9
10
12
13
14
15
Down arrival gong
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
11 Reserved
6
