User Manual 8 Description of Function Codes
- 251 -
8
These parameters are used to set the functions of four relay outputs and six open-collector outputs on the
HCB-B no-display parallel-serial conversion board.
The setting is effective to all HCB-Bs connected to the system.
8.18 Elevator Function Parameters
8.18.1 Floor Display Setting
Function Code Parameter Name Setting Range Default Unit
Property
FE-01
Floor 1 display
00: Display "0"
01: Display "1"
02: Display "2"
03: Display "3"
04: Display "4"
05: Display "5"
06: Display "6"
07: Display "7"
08: Display "8"
09: Display "9"
10: Display "A"
11: Display "B"
12: Display "G"
13: Display "H"
14: Display "L"
15: Display "M"
16: Display "P"
17: Display "R"
18: Display "-"
19: No display
20: Display "12"
21: Display "13"
22: Display "23"
23: Display "C"
24: Display "D"
25: Display "E"
26: Display "F"
27: Display "I"
28: Display "J"
29: Display "K"
30: Display "N"
31: Display "O"
32: Display "Q"
33: Display "S"
34: Display "T"
35: Display "U"
36: Display "V"
37: Display "W"
38: Display "X"
39: Display "Y"
40: Display "Z"
41: Display "15"
42: Display "17"
43: Display "19"
1901 -
☆
FE-02
Floor 2 display 1902 -
☆
FE-03
Floor 3 display 1903 -
☆
FE-04
Floor 4 display 1904 -
☆
FE-05
Floor 5 display 1905 -
☆
FE-06
Floor 6 display 1906 -
☆
FE-07
Floor 7 display 1907 -
☆
FE-08
Floor 8 display 1908 -
☆
FE-09
Floor 9 display 1909 -
☆
FE-10
Floor 10 display 0100 -
☆
Floor 11 to oor 30 display ···
FE-31
Floor 31 display 0301
-
☆
FE-35
Floor 32 display 0302
-
☆
FE-36
Floor 33 display 0303 -
☆
FE-37
Floor 34 display 0304 -
☆
FE-38
Floor 35 display 0305 -
☆
FE-39
Floor 36 display 0306 -
☆
FE-40
Floor 37 display 0307 -
☆
FE-41
Floor 38 display 0308 -
☆
FE-42
Floor 39 display 0309 -
☆
FE-43
Floor 40 display 0400 -
☆
These parameters are used to set the display of each oor. The setting range is 0000–9999, where the two
high digits indicate the display code of the ten’s digit, and the two low digits indicate the display code of the
unit’s digit.
