NICE3000
new
User Manual
4 Peripheral Devices and Options
- 69 -
4
Controller Model
Power Capacity
(kVA)
Input Current
(A)
Output Current
(A)
Adaptable Motor (kW)
NICE-L-C-4055 85.0 113.0 112.0 55.0
NICE-L-C-4075 114.0 157.5 150.0 75.0
NICE-L-C-4090 134.0 180.0 176.0 90.0
NICE-L-C-4110 160.0 214.0 210.0 110.0
NICE-L-C-4132 192.0 256.0 253.0 132.0
NICE-L-C-4160 231.0 307.0 304.0 160.0
4.2 List of Options
If any optional in the following table is required, specify it in your order.
Table 4-4 Options of the NICE3000
new
Name Model Function Remark
External braking
unit
MDBUN
It is provided for the modes of 37 kW and
above.
For details, see section 4.3.
PG card
MCTC-PG-A2
It is used to adapt to the push-pull and open-
collector incremental encoders.
-
MCTC-PG-D
It is used to adapt to the UVW differential
encoder and applied to synchronous motor.
It requires 5 V power supply.
-
MCTC-PG-E It is used to adapt to the SIN/COS encoder. -
MCTC-PG-F1
It is used to adapt to the absolute encoder
(Heidenhain ECN413/1313).
-
Car top board
(CTB)
MCTC-CTB
The MCTC-CTB is the car control board of
the NICE3000
new
. It has 8 DIs, 1 AI and 9
relay outputs (7 as standard conguration).
It can communicate with the CCB and HCB
simultaneously.
-
Hall call board
(HCB)
MCTC-HCB
The HCB receives the passenger calls and
displays the oor where the elevator is located
and the running direction. It can also be used
as car display board.
A number of HCB models
are available. For details,
see section 4.4.
Car call board
(CCB)
MCTC-CCB
The MCTC-CCB is another interface for
passengers to interact with the control system.
It mainly collects the car alls and outputs the
call indicator state.
-
Group control
board (GCB)
MCTC-GCB
The MCTC-GCB is used together with the
NICE3000
new
to implement group control of
multiple elevators.
-
External LED
operation panel
MDKE
It is the external LED display and operation
panel.
It provides the RJ45
interface for connecting to
the controller.
LED operator MDKE6
It is the external LED display and operation
panel.
It can be used for copying
parameter.
Extension cable MDCAB
It is a standard 8-core network cable and can
be connected to MDKE and MDKE6.
The cable length is 3 m in
the standard conguration.
