Page #248 background imageLoading...
Page #248 background image
NICE3000
new
User Manual 8 Description of Function Codes
- 247 -
8
FC-00 Bit0 = 0: The controller does not detect the short circuit to ground fault at power-on.
2. Protection at output phase loss
FC-01 Bit1 = 1: Protection at output phase loss is cancelled.
FC-01Bit1 = 0: The controller detects and reports the output phase loss fault.
3. Protection at input phase loss
FC-01 Bit14 = 1: Protection at input phase loss is cancelled.
FC-01 Bit14 = 0: The controller detects and reports the input phase loss fault.
8.16 Fault Information View
8.16.1 Designated Fault Information
Function Code Parameter Name Setting Range Default Unit Property
FC-06
Designated fault 0–99 0 -
FC-07
Designated fault code 0–9999 0 -
FC-08
Designated fault subcode 0–65535 0 -
FC-09
Designated fault month and day 0–1231 0 MM.DD
FC-10
Designated fault hour and minute 0–23.59 0 HH.MM
FC-11
Logic information of designated fault 0–65535 0 -
FC-12
Curve information of designated fault 0–65535 0 -
FC-13
Set speed upon designated fault 0.000–4.000 0 m/s
FC-14
Feedback speed upon designated fault 0.000–4.000 0 m/s
FC-15
Bus voltage upon designated fault 0.0–999.9 0 V
FC-16
Current position upon designated fault 0.0–300.0 0 m
FC-17
Output current upon designated fault 0.0–999.9 0 A
FC-18
Output frequency upon designated fault 0.00–99.99 0 Hz
FC-19
Torque current upon designated fault 0.0–999.9 0 A
These parameters are used to monitor the designated fault code. The information about the designated
fault code is saved in parameters of FC-07 to FC-19, and will not be overwritten.
8.16.2 Last 10 Fault Information
Function Code Parameter Name Setting Range Default Unit Property
FC-20
1st fault code 0–9999 0 -
FC-21
1st fault subcode 0–65535 0 -
FC-22
1st fault month and day 0–1231 0 MM.DD
FC-23
1st fault hour and minute 0–23.59 0 HH.MM
FC-24
2nd fault code 0–9999 0 -
FC-25
2nd fault subcode 0–65535 0 -
