Monarch nice3000 User Manual

NICE3000
new
User Manual
7 Function Code Table
- 165 -
7
7.3 Function Code Table
Function
Code
Parameter Name Setting Range Default Unit Property Page
Group F0: Basic parameters
F0-00 Control mode
0: Sensorless vector control
(SVC)
1: Closed-loop vector control
(CLVC)
2: Voltage/Frequency (V/F) control
1 -
★
192
F0-01
Command source
selection
0: Operation panel control
1: Distance control
1 -
★
192
F0-02
Running speed under
operation panel
control
0.050 to F0-04 0.050 m/s
☆
193
F0-03
Maximum running
speed
0.250 to F0-04 1.600 m/s
★
193
F0-04 Rated elevator speed 0.250–4.000 1.600 m/s
★
193
F0-05 Rated elevator load 300–9999 1000 kg
★
194
F0-06 Maximum frequency 20.00–99.00 50.00 Hz
★
194
F0-07 Carrier frequency 0.5–16.0 6.0 kHz
★
194
Group F1: Motor parameters
F1-00 Encoder type
0: SIN/COS encoder
1: UVW encoder
2: ABZ incremental encoder
3: ECN413/1313 absolute
encoder
0 -
★
195
F1-01 Rated motor power 0.7–75.0
Model
dependent
kW
★
195
F1-02 Rated motor voltage 0–600
Model
dependent
V
★
195
F1-03 Rated motor current 0.00–655.00
Model
dependent
A
★
195
F1-04
Rated motor
frequency
0.00–99.00
Model
dependent
Hz
★
195
F1-05 Rated motor speed 0–3000
Model
dependent
RPM
★
195
F1-06
Encoder initial angle
(synchronous motor)
0.0–359.9 0
Degree
(°)
★
196
F1-07
Encoder angle
at power-off
(synchronous motor)
0.0–359.9 0
Degree
(°)
★
196
F1-08
Synchronous motor
wiring mode
0–15 0 -
★
196
