NICE3000
new
User Manual 8 Description of Function Codes
- 243 -
8.13.8 Software Version View
Function Code Parameter Name Setting Range Default Unit Property
FA-05
MCB board software 0–65535 0 -
●
FA-06
Drive board software 0–65535 0 -
●
Fb-01
CTB software 00–999 0 -
●
FA-05 displays the software versions.
For example, if the MCB version is V16.00-F15.00-L01.00. When you view FA-05, the operation panel
displays the customer No. F15.00; after 3s, it displays the main version and sub version 16.00. Press
, and the operation panel displays the customized and process version L01.00.
FA-06 and FB-01 respectively displays the versions of the drive board and CTB.
8.13.9 Other Parameter Display
Function Code Parameter Name Setting Range Default Unit Property
FA-03
Current encoder angle 0.0–359.9 0.0 Degree (°)
●
FA-07
Heatsink temperature 0–100 0 °C
●
FA-11
Pre-torque current 0.0–200.0 0 %
●
FA-14
Set speed 0.000–4.000 0 m/s
●
FA-15
Feedback speed 0.000–4.000 0 m/s
●
FA-16
Bus voltage 0–999.9 0 V
●
FA-17
Present position 0.00–300.0 0 m
●
FA-18
Output current 0.0–999.9 0 A
●
FA-19
Output frequency 0.00–99.99 0 Hz
●
FA-20
Torque current 0.0–999.9 0 A
●
FA-21
Output voltage 0–999.9 0 V
●
FA-22
Output torque 0–100 0 %
●
FA-23
Output power 0.00–99.99 0 kW
●
FA-03 displays the real-time encoder angle. This parameter cannot be modied.
FA-07 displays the current temperature of the heatsink.
Normally, the heatsink temperature is below 40°C. When the heatsink temperature is too high, the system
lowers the carrier frequency automatically to reduce heat. When the heatsink temperature rises to a certain
value, the system reports the module overheat fault and stops running.
FA-11 displays the percentage of pre-torque current to the rated current (positive/negative display,
indicating driving or braking).
FA-14 to FA-23 display the current performance state of the system (the output torque and output power
supports positive/negative display).
