8 Description of Function Codes NICE3000
new
User Manual
- 242 -
8
Figure 8-27 FA-36 System state 1
RUN
LOCAL/REMOT FED/REV TUNE/TC
0
1
2
4
5
3
6
7
8
9
10
14
11
12
13
15
Present signal No.
State of present
signal
Each segment
indicates a signal
Segment ON: active
Segment OFF: inactive
Display
Meaning
Active Inactive
...
No. Signal No. Signal
0
1
2
3
4
5
7
Door close 1 button
Door open delay 1
Direct travel ride switch
Attendant switch
Direction change switch
Independent running switch
Fire emergency 2 switch
8
9
10
12
13
14
15
Door open 2 button
Door close 2 button
Door open delay 2
Reserved
Reserved
Reserved
Reserved
Door open 1 button
11 Reserved
6
Figure 8-28 FA-37 System state 2
RUN LOCAL/REMOT FED/REV TUNE/TC
0
1
24
5
3
6
7
8
9
10
14
11
12
13
15
Present signal No.
State of present
signal
Each segment
indicates a signal
Segment ON: active
Segment OFF: inactive
Display
Meaning
Active
Inactive
...
No.
Signal No.
Signal
0
1
2
3
4
5
7
Down direction display
Running state
System full-load
System overload
System half-load
System light-load
Reserved
8
9
10
12
13
14
15
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Up direction display
11 Reserved
6
